Using Branch Deployments (CI) with the dagster-cloud CLI#

In this guide, we'll walk you through setting up Continuous Integration (CI) Branch Deployments with a general continuous integration (CI) or git platform, using the dagster-cloud CLI.

Using this approach to branch deployments may be a good fit if:

• You don't use GitHub for version control
• You use an alternate CI platform
• You want full control over Branch Deployment configuration

If you use GitHub for version control or want Dagster to automate branch deployments, check out the dedicated Branch deployments with GitHub guide.

Prerequisites#

Utilizing Branch Deployments requires setting up two components: the Branch Deployment agent and CI platform. You'll need:

• Organization Admin permissions in Dagster+
• To install the dagster-cloud CLI
• The ability to configure your CI platform
• The ability to run a new agent in your infrastructure. This isn't required if you're using Serverless deployment.

Step 1: Generate a Dagster+ agent token#

In this step, you'll generate a token for the Dagster+ agent. The Dagster+ agent will use this to authenticate to the agent API.

1. Sign in to your Dagster+ instance.
2. Click the user menu (your icon) > Organization Settings.
3. In the Organization Settings page, click the Tokens tab.
4. Click the + Create agent token button.
5. After the token has been created, click Reveal token.

Keep the token somewhere handy - you'll need it to complete the setup.

Step 2: Create and configure an agent#

While you can use your existing production agent, we recommend creating a dedicated branch deployment agent. This ensures that your production instance isn't negatively impacted by the workload associated with branch deployments.

Step 3: Create a branch deployment using the dagster-cloud CLI#

Next, you'll create a branch deployment using the dagster-cloud CLI. When the state of a branch or merge request is updated, Dagster+ first expects these steps to occur:

1. A new image containing your code and requirements is built on the branch. Refer to the Dagster code requirements guide.

2. The new image is pushed to a Docker registry accessible to your agent. Note: The following examples assume the registry URL and image tag are stored in the LOCATION_REGISTRY_URL and IMAGE_TAG environment variables, respectively.

After the above has occurred:

1. Use the dagster-cloud CLI to create a branch deployment associated with the branch, as follows:

   BRANCH_DEPLOYMENT_NAME=$(
       dagster-cloud branch-deployment create-or-update \
           --organization $ORGANIZATION_NAME \
           --api-token $DAGSTER_CLOUD_API_TOKEN \ # Agent token from Step 1
           --git-repo-name $REPOSITORY_NAME \ # Git repository name
           --branch-name $BRANCH_NAME \ # Git branch name
           --commit-hash $COMMIT_SHA \ # Latest commit SHA on the branch
           --timestamp $TIMESTAMP # UTC unixtime timestamp of the latest commit
   )


   One or more additional parameters can optionally be supplied to the create-or-update command to enhance the Branch Deployments UI in Dagster+:

   BRANCH_DEPLOYMENT_NAME=$(
       dagster-cloud branch-deployment create-or-update \
           --organization $ORGANIZATION_NAME \
           --api-token $DAGSTER_CLOUD_API_TOKEN \
           --git-repo-name $REPOSITORY_NAME \
           --branch-name $BRANCH_NAME \
           --commit-hash $COMMIT_SHA \
           --timestamp $TIMESTAMP
           --code-review-url $PR_URL \ # URL to review the given changes, e.g.
                # Pull Request or Merge Request
           --code-review-id $INPUT_PR \ # Alphanumeric ID for the given set of changes
           --pull-request-status $PR_STATUS \ # A status, one of `OPEN`, `CLOSED`,
                # or `MERGED`, that describes the set of changes
           --commit-message $MESSAGE \ # The message associated with the latest commit
           --author-name $NAME \ # A display name for the latest commit's author
           --author-email $EMAIL \ # An email for the latest commit's author
           --author-avatar-url $AVATAR_URL # An avatar URL for the latest commit's author
           --base-deployment-name $BASE_DEPLOYMENT_NAME # The main deployment that will be compared against. Default is 'prod'
   )


   If the command is being executed from the context of the git repository, you can alternatively pull this metadata from the repository itself:

   BRANCH_DEPLOYMENT_NAME=$(
       dagster-cloud branch-deployment create-or-update \
           --organization $ORGANIZATION_NAME \
           --api-token $DAGSTER_CLOUD_API_TOKEN \
           --git-repo-name $REPOSITORY_NAME \
           --branch-name $BRANCH_NAME \
           --read-git-state # Equivalent to passing --commit-hash, --timestamp
                            # --commit-message, --author-name, --author-email
   )


2. Deploy the code to the branch deployment:

   dagster-cloud deployment add-location \
       --organization $ORGANIZATION_NAME \
       --deployment $BRANCH_DEPLOYMENT_NAME \
       --api-token $DAGSTER_CLOUD_API_TOKEN \
       --location-file $LOCATION_FILE \
       --location-name $LOCATION_NAME \
       --image "${LOCATION_REGISTRY_URL}:${IMAGE_TAG}" \
       --commit-hash "${COMMIT_SHA}" \
       --git-url "${GIT_URL}"


   Refer to the Code location guide for more info on how a location's details are specified.

Step 4: Access the branch deployment#

Now that Branch Deployments are configured, you can check out the preview in Dagster+.

Click the deployment switcher to view your workspace's branch deployments:
